ISO 14644-1 CLEANROOM HANDLING
Cleanroom Overhead Crane
0.5–20 t capacity · Spans up to 31.5 m · Low-particle design · Smooth VFD motion.
- ISO Class 5–8 options
- Sealed drives (IP55/IP65)
- Low-outgassing cabling
- Food-grade lubricants
Pharma, semiconductor, Li-ion, optics & food plants · ISO / GMP-oriented design · FAT photos & docs on request.
- ISO 14644-1 Class 5–8
- CE Marking
- ISO 9001 Factory
- 2-Year Warranty
Low-Particle Design
Enclosed trolleys, smooth surfaces and minimized ledges to reduce particle traps and dust build-up.
Clean Materials
Epoxy finish (RAL 9016) or stainless packages with food-grade lubricants for sensitive processes.
Sealed & Protected
IP55/IP65 drives, sealed bearings and stainless fasteners where needed to support your class target.
Precise & Quiet
VFD hoist/travel, low noise profile and fine load positioning for delicate handling steps.
Why Cleanroom Crane?
- Particle control: smooth finishes, sealed drives and cable management to minimize shedding.
- Materials & grease: epoxy or stainless finishes; NSF H1 food-grade lubricants on request.
- Cabling: low-outgassing, cleanroom-rated dress packs with stainless trays and clamps.
- Documentation: material certificates, paint datasheets and FAT records supplied per project.
Build Your Spec
Budget Estimate
Auto-updates from “Build Your Spec”. Ex-works budgetary range. Final quote after drawings & class review.
- Capacity
- —
- Span
- —
- Lift
- —
- Class
- —
- Surface
- —
- Sealing
- —
- Hoist
- —
- Cabling
- —
- Lubrication
- —
- Control
- —
- Quantity
- —
- Timeline
- —
Applications & Examples
Technical Specifications
| Type | Top-running single-girder overhead crane with cleanroom package |
|---|---|
| Rated Capacity | 0.5–20 t (custom on request) |
| Span | 5–31.5 m |
| Lift Height | 4–16 m typical |
| Cleanliness | ISO 14644-1 Class 5–8 (configuration dependent) |
| Finish | Epoxy RAL 9016 or stainless packages (304/316), smooth surface profiles |
| Sealing | IP55/IP65 drives; sealed bearings |
| Cabling | Low-outgassing dress packs; stainless trays and clamps |
| Lubrication | Standard or food-grade (NSF H1) on request |
| Hoist | Wire-rope or chain; low-noise, VFD hoist/travel |
| Control | Pendant / Radio; PLC interlocks optional |
| Power | 380–480 V, 50/60 Hz, 3Ph |
| Safety | Overload limiter, limit switches, e-stop; optional anti-collision |
| Documentation | Material certs, paint datasheets, FAT records (scope per project) |
From Inquiry to Commissioning
- 01 · SizingShare load, span & bay drawings
- 02 · ProposalCleanroom package, finish & seals
- 03 · ManufacturingFAT report with photos/video
- 04 · DeliveryPackaging & documentation pack
- 05 · CommissioningOn-site or remote guidance
Get Pricing & Lead Time
Tell us capacity, span, lift, cleanliness class, surface & sealing, cabling and lubrication. We’ll tailor the package & drawings to your protocol.
Note
Builder and estimate are budgetary only. Final offer confirms layout, class, finishes and documentation scope.
