Crane Rails & Runway Systems.
DIN A / QU, ASCE and square bar rails with matching clips, elastomer pads, soleplates and support components. Configure a preliminary runway package, check indicative quantities and send one coordinated RFQ.
- DIN / QURail profiles
- ASCERail profiles
- Rail + PartsCombined enquiry
RAIL PROFILES / CLIPS / PADS / SOLEPLATESOne runway. One coordinated parts package.From rail profile to fixing and installation interface.
- 01Set wheel load
- 02Choose rail & fixing
- 03Send technical RFQ
01 / System scope
More than the rail.
A complete runway interface.
Select the right profile family, consider fixing and isolation requirements and bring accessories into the same enquiry for technical review.
Rail profiles
DIN A / QU, ASCE and square bar options for bridge, gantry and monorail applications.
Clips & welding
Clip-fixed or welded arrangements, selected with installation constraints in mind.
Pads & soleplates
Elastomer rail pads, levelling interfaces, steel soleplates and grout where required.
Project coordination
Share load, duty, environment and drawings so the complete assembly can be reviewed.
02 / Rail families
Explore the main profiles.
Use these product families as a starting point. Final rail dimensions and steel grade must follow the crane, wheel and runway design.
DIN A / QU Rails
Indicative series: A65–A150 / QU70–QU150. Suitable family for preliminary crane runway matching.
Configure DIN / QU
ASCE Rails
Indicative series: ASCE 60–115. Consider matching width, fixing and wheel contact requirements.
Configure ASCE
Square Bar Rails
Nominal 40–60 mm square bar options for suitable smaller applications; suitability requires verification.
Configure Square Bar03 / Interactive configuration
Build your runway package.
Adjust values below. The live summary calculates a preliminary profile suggestion, rail length, bar count, joint count and fixing quantity for enquiry planning.
Project requirements
The more accurately you enter the load and installation conditions, the more relevant your initial RFQ.
04 / Early-stage planning
Budget estimate,
not a firm offer.
The figures update with your selection and retain the illustrative unit-cost assumptions from the original page. They are for rough internal planning only. Send drawings and the final bill of materials for a commercial quotation.
- Profile & length
- —
- Fixing
- —
- Pad / support
- —
- Requested timeline
- —
Non-binding mathematical indication, excluding freight, duties, taxes, engineering/installation and any unmodelled materials. No market-price verification. Engineering and commercial confirmation required.
05 / Applications
Rail & fixing details.
Images are for product-family reference. Final clip positions, supports, joints and mounting dimensions depend on the approved rail layout.
06 / Technical overview
Specifications
& supply scope.
Technical dimensions and compliance documentation should be confirmed for the selected item and destination market.
| Rail families | DIN A / QU (A65–A150 / QU70–QU150), ASCE 60–115, Square Bar 40–60 mm |
|---|---|
| Fixing method | Clip-fixed or welded; indicative clip spacing 300–800 mm |
| Pads & isolation | Elastomer rail pads; intended for vibration/noise reduction and interface support, subject to design |
| Soleplates & grout | Steel soleplates with grout underfill; shims and levelling as required |
| Other accessories | End-stop buffers, rail sweeper, derailment guard, storm brake / rail clamp (as applicable) |
| Environment | Indoor, outdoor, marine / coastal and dusty / harsh; corrosion treatment to be specified |
| Technical documents | Layout drawing, clip plan, joint plan and applicable inspection records subject to order scope |
Series shown reflect the supplied original page, not a promise that each profile is available in every steel grade and length.
